A blue/grey film, providing heat and glare reduction, used extensively on residential buildings and commercial when don’t want a dark film.

Description

Benefits

  • Popular on residential & commercial buildings with clear laminated glass.
  • Advanced sputtering technology.
  • Stabilised metals used to guarantee original colour.
  • Good glare and fade reduction.
  • Reduces energy costs all year round.
  • Provides some daytime privacy on double glazing.
  • World’s toughest scratch resistant surface.
  • Clear distortion free adhesive.
  • Low internal reflection.

Application

  • Clear Float or Laminated – YES*
  • Tinted Float or Laminated – YES*
  • Toughened – YES
  • Wire Cast – NO
  • Double Glazed- YES*

* In certain applications a thermal safety assessment recommendation is required prior to application

DST LR2

Additional information

Total Solar Energy Rejection (Heat)

56%

Glare Rejection

58%

Ultra Violet Rejection

99%+

Visible Light Transmitted

37%

Solar Energy Reflected

25%

Solar Energy Absorbed

44%

Estimated Fade Reduction*

69%

Visible Light Reflected (External)

27%

Shading Co-efficient

0.50

U-Value (W/Sq.m.k.)

5.79

Solar Heat Gain Co-efficient

0.44

Colour

Blue Grey

Film Construction

Clear Sputtered

Visual Characteristics

Low Reflective

Laminates

Double

Metal Type

Aluminium/Nickel Alloy

Thickness (microns)

38

Scratch Resistant

Yes

Warranty

12 years Commercial & Residential (vertical), 5 years (horizontal). 12 Months Workmanship

*

*This data is a guide enabling an estimate only of fade reduction.
As there are variables that cause fading, it would be impossible to give an exact figure. The data therefore does not constitute warranty.
