A highly reflective film manufactured for application to external surface of glass where thermal stress or obstructions are a major consideration
Benefits
Application
* In certain applications a thermal safety assessment recommendation is required prior to application
| Total Solar Energy Rejection (Heat) | 83% |
|---|---|
| Glare Rejection | 85% |
| Ultra Violet Rejection | 99%+ |
| Visible Light Transmitted | 13% |
| Visible Light Reflected (External) | 65% |
| Solar Energy Reflected | 65% |
| Solar Energy Absorbed | 26% |
| Estimated Fade Reduction* | 82% |
| Shading Co-efficient | 0.20 |
| U-Value (W/Sq.m.k.) | 5.79 |
| Solar Heat Gain Co-efficient | 0.17 |
| Colour | Silver |
| Film Construction | Clear Metallised |
| Visual Characteristics | High reflective |
| Laminates | Double |
| Metal Type | Aluminium |
| Thickness (microns) | 38 |
| Scratch Resistant | No |
| Warranty | 7 years (vertical), 5 years (horizontal not less than 20 degrees sloping surface). 12 Months Workmanship |
| * | *This data is a guide enabling an estimate only of fade reduction. |
| Heat Rating | High Rejection |
| Fade Rating | Medium to High Ability-up to 82% |
| Fire Rating | Exceeds Class A Fire Rating |
| Glare Rating | High Optical Comfort |
| Safety Rating | Medium to High Ability |
| Natural Light | Medium Retention |
| UPF Rating | Excellent Protection Category |
| Daytime Privacy | High Level of Privacy |
| Visual Acuity | 88% |
