    DST SEC1

    A clear safety film applied to the inside surface of glass to give increased strength and safety. Provides
    protection from injury.



    Physical Properties

    A. Tensile Strength: 33,100 Pounds per square inch
    B. Break Strength: 132 Pound force per inch width
    C. Elongation at Break: 167%
    D. Peel Strength: 3200 Grams per inch width

    Categories: ,

    Description

    Benefits

    •  Provides protection in schools, kindergartens and public access areas.
    • Visibility undetectable.
    • Almost three times thicker than normal film, increasing strength and safety of glass.
    • Manufactured to comply with the AS/NZS2208 when applied to 3mm glass and thicker.
    • Scratch resistant coating
    • Maintains duty of care.

    Application

    • Clear Float or Laminated – YES
    • Tinted Float or Laminated – YES
    • Toughened – YES
    • Wire Cast – YES
    • Double Glazed- YES
    DST SEC1

    Additional information

    Total Solar Energy Rejection (Heat)

    14%
    Glare Rejection

    2%
    Ultra Violet Rejection

    99%+
    Visible Light Transmitted

    87%
    Visible Light Reflected (External)

    9%
    Shading Co-efficient

    0.94
    Solar Energy Reflected

    7%
    Solar Energy Absorbed

    7%
    Solar Heat Gain Co-efficient

    0.86
    U-Value (W/Sq.m.k.)

    5.8
    Colour

    Clear
    Visual Characteristics

    Non Reflective
    Laminates

    Single
    Metal Type

    No metal
    Thickness (microns)

    100
    Scratch Resistant

    Yes
    Warranty

    12 years Commercial & Residential. 12 Months Workmanship
    *

    *This data is a guide enabling an estimate only of fade reduction.
    As there are variables that cause fading, it would be impossible to give an exact figure. The data therefore does not constitute warranty.
