A clear safety film applied to the external surface of glass to give increased strength and safety. Provides protection
from injury.
Physical Properties
A. Tensile Strength: 27,614 Pounds per square inch
B. Break Strength: 193 Pound force per inch width
C. Elongation at Break: 211%
D. Peel Strength: 3200 Grams per inch width
Benefits
Application
| Total Solar Energy Rejection (Heat) | 14% |
|---|---|
| Glare Rejection | 3% |
| Ultra Violet Rejection | 99%+ |
| Visible Light Transmitted | 87% |
| Visible Light Reflected (External) | 10% |
| Shading Co-efficient | 0.93 |
| Solar Energy Reflected | 9% |
| Solar Energy Absorbed | 7% |
| Visible Light Reflectance | 9% |
| Solar Heat Gain Co-efficient | 0.86 |
| U-Value (W/Sq.m.k.) | 5.8 |
| Colour | Clear |
| Visual Characteristics | Non Reflective |
| Laminates | Single |
| Metal Type | No metal |
| Thickness (microns) | 175 |
| Scratch Resistant | Yes |
| Warranty | 12 years Commercial & Residential. 12 Months Workmanship |
| * | *This data is a guide enabling an estimate only of fade reduction. |
